Saving ViewModel State with Serialization

We already know that Process Death is the rule, not the exception, and we’ve seen how to solve those issues with State Management.

In a ViewModel, the tool for the job is SavedStateHandle. But the way we’re usually taught to use it doesn’t scale past two or three fields, and I’d like to show you an alternative that scales to any screen, for free.

What we’re building

Let’s take a small, boring screen: a recipe draft. The user types a title, adds ingredients one by one, and walks through a two-step wizard.

data class Ingredient(
    val name: String,
    val grams: Int,
)

data class RecipeUiState(
    val title: String = "",
    val ingredients: List<Ingredient> = emptyList(),
    val step: Int = 0,
    val isLoading: Boolean = false,
)

Nothing here comes from the server. If the user typed it and we lose it, they typed it for nothing.

What is usual

The usual approach is to treat SavedStateHandle as a Map<String, Any?> and save field by field:

class RecipeViewModel(
    private val savedStateHandle: SavedStateHandle,
) : ViewModel() {

    private val _uiState = MutableStateFlow(
        RecipeUiState(
            title = savedStateHandle["title"] ?: "",
            step = savedStateHandle["step"] ?: 0,
        )
    )
    val uiState: StateFlow<RecipeUiState> = _uiState.asStateFlow()

    fun onTitleChanged(title: String) {
        savedStateHandle["title"] = title
        _uiState.update { it.copy(title = title) }
    }

    fun onStepChanged(step: Int) {
        savedStateHandle["step"] = step
        _uiState.update { it.copy(step = step) }
    }

    fun onIngredientAdded(ingredient: Ingredient) {
        val ingredients = _uiState.value.ingredients + ingredient
        savedStateHandle["ingredients"] = ArrayList(ingredients) // ⚠️ compiles, crashes later
        _uiState.update { it.copy(ingredients = ingredients) }
    }
}

This is what most codebases do, and it mostly works. It has three problems:

• Every field is written twice, once into the StateFlow and once into the handle. The day someone adds a field and forgets the second line, the bug is invisible until a user comes back from the background.
• The string keys are untyped. savedStateHandle["step"] returning null because someone renamed a key is a compile-time non-event and a runtime 0.
• List<Ingredient> doesn’t fit — and nothing tells us so. This one deserves its own section.

The ingredients line is a trap

A Bundle only takes a fixed set of types, so Ingredient has to become Parcelable. Fine. The problem is when we find out that we forgot.

We might expect that savedStateHandle["ingredients"] = ArrayList(ingredients) fails to compile. It doesn’t. SavedStateHandle’s accessors are declared with a completely unbounded generic:

@MainThread public operator fun <T> get(key: String): T?
@MainThread public operator fun <T> set(key: String, value: T?)

No T : Parcelable, no T : Serializable. Any type at all satisfies that signature, so the compiler waves our Ingredient straight through.

Surely set() catches it at runtime, then? It does validate — but look at what it validates against (isAcceptableType):

internal actual fun isAcceptableType(value: Any?): Boolean =
    value == null || ACCEPTABLE_CLASSES.any { classRef -> classRef.isInstance(value) }

And in that ACCEPTABLE_CLASSES list, with a comment that says everything:

// type erasure ¯\_(ツ)_/¯, we won't eagerly check elements contents
ArrayList::class.java,

ArrayList is an acceptable class, and by design nothing looks inside it. So our line compiles, passes validation, and the set() returns happily. The failure only comes later, when the Bundle is really written out to a Parcel:

java.lang.IllegalArgumentException: Can't put value with type class java.util.ArrayList into saved state

⚠️ Read that sequence again, because it’s the whole point: the mistake is invisible at compile time, invisible at set() time, and surfaces at process-save time — on a device, in front of a user. It is the single worst moment for a bug to introduce itself.

And that’s before we get to the fact that making Ingredient Parcelable puts an Android-only annotation on a domain model — which simply isn’t an option if that model lives in a Kotlin Multiplatform module.

We’re also saving things we shouldn’t. isLoading = true restored after process death gives the user a spinner that will never stop, because the coroutine that was going to flip it back died with the process.

The alternative: save the whole state, once

Here’s the idea: our UiState is already the single source of truth for the screen. Instead of picking it apart into keys, we serialize the whole thing into one String and put that String in the handle.

SavedStateHandle is perfectly happy holding a String, and a String is perfectly happy holding a whole object graph.

Step 1: annotate the state

@Serializable
data class Ingredient(
    val name: String,
    val grams: Int,
)

@Serializable
data class RecipeUiState(
    val title: String = "",
    val ingredients: List<Ingredient> = emptyList(),
    val step: Int = 0,
    @Transient val isLoading: Boolean = false,
)

That’s it for the model. Two annotations, and the nested List<Ingredient> comes along for the ride at no extra cost.

ℹ️ @Transient is how we say “this field is not worth restoring”. Loading flags, one-time actions, anything that a coroutine owns and will recompute anyway. Note that @Transient fields must have a default value, which is exactly the behaviour we want: they come back as false, not as they were.

Step 2: save and restore in the ViewModel

private const val KEY_STATE = "ui_state"

class RecipeViewModel(
    private val savedStateHandle: SavedStateHandle,
) : ViewModel() {

    private val _uiState = MutableStateFlow(restoreState() ?: RecipeUiState())
    val uiState: StateFlow<RecipeUiState> = _uiState.asStateFlow()

    private fun update(block: RecipeUiState.() -> RecipeUiState) {
        val newState = _uiState.updateAndGet { it.block() }
        savedStateHandle[KEY_STATE] = Json.encodeToString(newState)
    }

    private fun restoreState(): RecipeUiState? =
        savedStateHandle.get<String>(KEY_STATE)?.let { Json.decodeFromString(it) }

    fun onTitleChanged(title: String) = update { copy(title = title) }

    fun onIngredientAdded(ingredient: Ingredient) = update {
        copy(ingredients = ingredients + ingredient)
    }

    fun onStepChanged(step: Int) = update { copy(step = step) }
}

Look at what happened to the bottom half of that class. Every event handler is a one-liner, and not a single one of them mentions saving. The update() function is the only place that touches SavedStateHandle, so a new field can never be forgotten — it was already inside the state we just serialized.

flowchart LR
    A[UiEvent] --> B["update { copy(...) }"]
    B --> C[MutableStateFlow]
    B --> D["Json.encodeToString()"]
    D --> E[SavedStateHandle]
    E -->|Process Death| F["Json.decodeFromString()"]
    F --> C

If you’re writing an MVI base class, update() is exactly where this belongs — write it once in MVIViewModel, and every screen in the app becomes process-death-proof by inheriting it.

⚠️ Serializing on every keystroke is cheap (it’s a small object), but it isn’t free. If a screen holds a genuinely large state, serialize in onCleared() and on a debounce instead of on every update.

Not using kotlinx.serialization?

The pattern is the pattern — only the two Json calls change. With Gson:

private val gson = Gson()

private fun save(state: RecipeUiState) {
    savedStateHandle[KEY_STATE] = gson.toJson(state)
}

private fun restoreState(): RecipeUiState? =
    savedStateHandle.get<String>(KEY_STATE)?.let { gson.fromJson(it, RecipeUiState::class.java) }

No @Serializable needed, and the equivalent of @Transient is Kotlin’s @Transient (kotlin.jvm.Transient), which maps to the Java transient keyword that Gson skips. Moshi works the same way with @JsonClass(generateAdapter = true).

The only real difference is that kotlinx.serialization does its work at compile time, so it will tell you at build time that a field of yours isn’t serializable, while Gson will find out at runtime, in front of a user. That, and it’s the one that works in a Kotlin Multiplatform module.

How do we actually test this?

This is the part that usually gets skipped, and it’s the part that matters. A state restoration that was never tested is a state restoration that doesn’t work.

The good news: we no longer need an emulator, adb shell am kill, or a “Don’t keep activities” toggle to test this. Since androidx.lifecycle:lifecycle-viewmodel-testing there’s a viewModelScenario with a recreate() function that does exactly what the system does — it takes the current SavedStateHandle contents, throws the ViewModel away, and builds a new one from that saved state.

testImplementation("androidx.lifecycle:lifecycle-viewmodel-testing:$lifecycleVersion")

And the test:

@Test
fun `recipe draft survives process death`() {
    viewModelScenario { RecipeViewModel(createSavedStateHandle()) }.use { scenario ->
        scenario.viewModel.apply {
            onTitleChanged("Pancakes")
            onIngredientAdded(Ingredient(name = "Flour", grams = 250))
            onStepChanged(1)
        }

        scenario.recreate() // 💀 process death happens here

        val restored = scenario.viewModel.uiState.value
        assertEquals("Pancakes", restored.title)
        assertEquals(listOf(Ingredient(name = "Flour", grams = 250)), restored.ingredients)
        assertEquals(1, restored.step)
    }
}

scenario.viewModel after recreate() is a different instance. Everything that comes back came back through the SavedStateHandle, which means this test fails the moment someone breaks the save path.

And the other half of the test, the one that’s just as important:

@Test
fun `transient state does not survive process death`() {
    viewModelScenario { RecipeViewModel(createSavedStateHandle()) }.use { scenario ->
        scenario.viewModel.onSaveClicked() // sets isLoading = true

        scenario.recreate()

        assertFalse(scenario.viewModel.uiState.value.isLoading)
    }
}

That’s the test that pins down @Transient and stops a future refactor from restoring a user into an eternal spinner.

ℹ️ These are plain JVM unit tests. They run in milliseconds, on CI, on every pull request — which is the only way process-death coverage stays alive over time. Compare that to detecting these issues with Appium or with Maestro: those E2E tests are still worth having for the full-app flows, but they’re far too slow to be your first line of defence.

Conclusion

Two annotations on the state, one update() function, one recreate() test:

• @Serializable on the UiState — nested lists and objects included, for free
• @Transient on anything a coroutine owns — loading flags, one-time actions
• One place that writes to SavedStateHandle — so no field can ever be forgotten
• viewModelScenario { }.recreate() — process death as a fast JVM unit test

The reason I like this so much is that it removes the discipline requirement. The usual approach works fine as long as every developer remembers, on every field, forever. This one works because there’s nothing to remember.

Let me know what you think or if you have questions in the comments! 📝

By the way, I’m also on Twitter and LinkedIn, so feel free to connect there too!

Stay tuned for more posts on Android Development! 🚀
